VBOX Video HD2 - HDMI Track Package
VBOX Video HD2 - HDMI Track Package
The VBOX HD2 HDMI Track Package includes roll cage camera mounts and an un-terminated power cable instead of the standard suction camera mounts and cigar lighter power supply cable. This means easier fitment in vehicles fully prepared for racing.
This VBOX Video HD2 system has an HDMI video output allowing you to stream real-time video and audio to an HDMI compatible monitor, recorder or streaming device.
VBOX HD2 HDMI can be used to give live coverage of motorsport events for TV or social media, provide race teams with the ability to give instant driver feedback, or can act as a rear-view camera. It comes with an HDMI port and locking pin to make sure our custom cable has a secure connection.
VBOX Video HD2 features 1080p 60fps video, real-time synchronized video/data with graphical overlay, Bluetooth and WiFi connectivity. The internal 10 Hz GPS engine recognizes the race track you are driving and automatically configures the track map and lap timing. Automatic recording, a pre-record buffer and internal power backup ensure that you capture absolutely all of the race action. Video can be recorded at thirty frames per second to SD card or USB flash drive.
Download the datasheet here.
Package Contents
HD2 Logger with HDMI connector
2 Cameras
Microphone
2 roll cage camera mounts
Un-terminated in-car power supply
Antenna
32 GB SD card
HDMI cable (0.9 m) with locking screws
OLED Predictive Lap timing display - Only included if option '[/D]' selected.
Quality Settings & Log Rates
Low - 3.5 GB/hr
Medium (default) - 5.4 GB/hr
High - 7 GB/hr
Graphics are overlaid in real time – also in high definition. With the high resolution afforded by the 1080p 60fps output, this gives the user great scope for fantastic dashboard and gauge layouts. The graphics are fully customizable but several default scenes are available.
To aid in setting up the cameras, an app for Android and iOS devices connects via the VBOX Video’s inbuilt WiFi to aid in getting the view just right, with real time camera output being displayed on the mobile device’s screen. The app also features some elements of the system setup for absolute convenience.
Remote start/stop logging is taken care of via a Bluetooth unit that can be conveniently mounted next to the driver.
VBOX Video HD2 represents the very latest in cutting edge technology within the VBOX Motorsport range, giving you a competitive advantage no matter what level of motorsport you compete in.
Features
Dual Camera 1080p system
10 Hz GPS data logging
HDMI video output
Records to SD card or USB
Predictive Lap Timing (with OLED display)
Real-time, high-definition graphic overlay
MP4 video & audio recording
Compatible with AiM dashboards or loggers
VideoSplit - simple to use video editing software to help you share laps and data with friends and on social media
Internal power backup for reliable recording
Up to 80 CAN channel inputs
USB 2.0 host interface (for recording to USB flash drive)
Camera preview over WiFi
Bluetooth LE connectivity
Built-in track database
Compatible with MoTeC
